    Heat Treated Steel

    Cold Work Steel

    BÖHLER K340 ISODUR DC-53
    Heat Treatment HRC 52-62
    Description
    BÖHLER K340 ISODUR, an 8% chromium steel, is produced using the electro-slag remelting (ESR) method. This by BÖHLER developed and proven remelting technology, ensures extremely low micro and macro segregations and gives the material the purity and homogeneity necessary for excellent performance in practice.

    Property Features
    Key reasons for the broad application spectrum of BÖHLER K340 ISODUR:
    • Outstanding toughness
    • Excellent compressive strength
    • Very good machinability due to homogeneous structure
    • Smaller dimensional changes
    BÖHLER K340 ISODUR is particularly suitable for the following application areas:
    • Cutting
    • Blanking
    • Cold forming
    Specification
    Compressive strength Stability heat Toughness Wear resistance Wear resistance adhesive
    ★★★☆☆ ★★★★☆ ★★★☆☆ ★★★☆☆ ★★★★☆

    Chemical Composition
    C Si Mn Cr Mo V
    1.10 0.90 0.40 8.30 2.10 0.50
    Chemical composition (average %)

    Applications
    • Coining
    • Cold Forming
    • Cold Forming / Coining
    • Comp. for Chemical plants (incl. LNG, FGD, Urea, LDPE, etc.)
    • Components for Recycling Industry
    • Comps. for Equip. Below Ground (Boring, Shafts, etc.)
    • CPI (inc. LNG, Urea)
    • Extrusion
    • Fine Blanking / Blanking / Stamping
    • Fine Blanking, Stamping, Blanking
    • Forging (Hot / Semi-hot)
    • General Components for Mechanical Engineering
    • Gravity / Low Pressure Die-Casting
    • Injection Components
    • Lamps/Lenses for Automotive
    • Machine knife (for producers)
    • Medical
    • Mining and Rock Handling
    • Oil & Gas
    • Other Oil and Gas + CPI comps.
    • Pill punching dies
    • Powder Pressing
    • Rolling
    • Rolls
    • Screws and Barrels
    • Shearing / Machine Knives
    • Turbine and Engine Parts (Aerosp)
    • Wear parts
    • Well Logging Tools
