Sensor
Diffuse sensors with intensity difference Baumer O300.ZL-11181089
| general data |
| type |
intensity difference |
| light source |
pulsed red laser diode |
| sensing distance Tw |
10 ... 250 mm |
| repeat accuracy |
< 0.1 mm at laser focus |
| power on indication |
LED green |
| light indicator |
LED yellow |
| sensing distance adjustment |
qTeach |
| laser class |
1 |
| distance to focus |
80 mm |
| wave length |
656 nm |
| suppression of reciprocal influence |
yes |
| alignment optical axis |
< 2° |
| electrical data |
| response time / release time |
< 0.1 ms |
| voltage supply range +Vs |
11 ... 30 VDC |
| current consumption max. (no load) |
30 mA |
| current consumption typ. |
25 mA |
| voltage drop Vd |
< 2.5 VDC |
| output function |
light / dark operate |
| output circuit |
PNP complementary |
| output current |
< 100 mA |
| short circuit protection |
yes |
| reverse polarity protection |
yes |
| mechanical data |
| width / diameter |
12.9 mm |
| height / length |
32.3 mm |
| depth |
23 mm |
| type |
rectangular |
| housing material |
plastic (ASA, PMMA) |
| front (optics) |
PMMA |
| connection types |
connector M8 4 pin |
| ambient conditions |
| operating temperature |
-25 ... +60 °C |
| protection class |
IP 67 |
