FA-MOD PLC: Analogue I/O Module
| Series | MELSEC-Q SERIES |
|---|
| Type | ANALOG INPUT/OUTPUT COMBINED |
|---|
| Power Supply (V) | 24 |
|---|
| Current Type | DC |
|---|
| Occupied I/O Points on PLC | 16 |
|---|
| Integrated Analogue Inputs | 4 |
|---|
| Integrated Analogue Outputs | 2 |
|---|
| Input Voltage Range (V) | -10-10; 0-10; 0-5; 1-5 |
|---|
| Input Current Range (mA) | 0-20; 4-20 |
|---|
| Output Voltage Range (V) | -10-10; 0-5; 1-5 |
|---|
| Output Current Range (mA) | 0-20; 4-20 |
|---|
| Wiring | SCREW |
|---|
| Int. Current Consumption (A) | 0,17 |
|---|
Product Dimensions & Weight
| Width (mm) | 27,4 |
|---|
| Height (mm) | 98 |
|---|
| Depth (mm) | 112 |
|---|
| Weight (kg) | 0,23 |
|---|
Conformity
| CE | COMPLIANT |
|---|
| UL/cUL | COMPLIANT |
|---|
| EAC | COMPLIANT |
|---|
| Shipping Approvals | ABS,BV,DNV GL,LR,NK,RINA |
|---|
| UKCA | COMPLIANT |
|---|
