    Miniature photoelectric sensors SICK W130 Laser

    Type:WSE130L-52
    Part No.:6029865
    add to cart Inquiry Now
    Features
    Sensor/ detection principle Through-beam photoelectric sensor
    Dimensions (W x H x D) 13.4 mm x 47 mm x 52.9 mm
    Housing design (light emission) Rectangular
    Sensing range max. 0 m ... 3.5 m
    Type of light Visible red light
    Light source Laser 1)
    Laser class 1, EN 60 825-1
    XXX 30 mm x 2.5 mm (parallel)
    Adjustment None
    • 1) Average service life: 50,000 h at TU = +25 °C.


    Mechanics/electronics
    Connection type Cable with male connector, 2 m 1) 2)
    Cable material PVC/PBT
    Protection class III
    Weight 100 g
    Housing material Plastic, PC
    Optics material Plastic, PMMA
    Enclosure rating IP67
    Ambient operating temperature –10 °C ... +55 °C
    Ambient temperature, storage –25 °C ... +70 °C
    • 1) Connection between sensor head and evaluation unit with system-specific connector.
    • 2) Do not bend below 0 °C.


    Classifications
    ECl@ss 5.0 27270901
    ECl@ss 5.1.4 27270901
    ECl@ss 6.0 27270901
    ECl@ss 6.2 27270901
    ECl@ss 7.0 27270901
    ECl@ss 8.0 27270901
    ECl@ss 8.1 27270901
    ECl@ss 9.0 27270901
    ECl@ss 10.0 27270901
    ECl@ss 11.0 27270901
    ETIM 5.0 EC002716
    ETIM 6.0 EC002716
    ETIM 7.0 EC002716
    UNSPSC 16.0901 39121528
