Sensor
Ultrasonic through beam sensors Baumer U300.TA0-ZZZX.72N
| Technical Data |
| General Data |
| emitter / receiver |
emitter |
| scanning range Sd |
0 ... 1000 mm |
| scanning range far limit Sde |
0 ... 1000 mm |
| sonic frequency |
310 kHz |
| power on indication |
LED green |
| Electrical Data |
| voltage supply range +Vs |
12 ... 30 VDC |
| current consumption typ. |
25 mA |
| residual ripple |
< 10 % Vs |
| short circuit protection |
yes |
| reverse polarity protection |
yes, Vs to GND |
| Mechanical Data |
| type |
rectangular |
| housing material |
plastic (ASA, PMMA) |
| width / diameter |
12.9 mm |
| height / length |
32.2 mm |
| depth |
23 mm |
| connection types |
connector M12 8 pin |
| Ambient Conditions |
| operating temperature |
-25 ... +65 °C |
| storage temperature |
-40 ... +75 °C |
| protection class |
IP 67 |
